Nickel Chromium Mesh

The Nickel Chromium Mesh also called as Ni80Cr20 mesh is comprised of 80% Ni and 20% Cr. It is popular to offer the superior resistance to corrosion and oxidation at the elevated temperature and large melting point of 1400oC. It is non-deformable and offers almost double resistance than the other nichrome alloys. The wire mesh attains high coefficient of electrical resistively at the elevated temperatures. So it reduces the flow of current and generates large amount of heat when heated extensively.

Mesh Specifications
Mesh Size 0.2Mesh/Inch to 250Mesh/Inch
Thickness 0.1mm-5.0mm
Aperture Rate 10%-90%

Physical Properties of Nichrome Mesh Ni80Cr20:
Density 8.65Mg/m3
Ductility 0.7
Melting Point 1400oC
Hardness 1000 MPa
Maximum Service Temperature 1070 K
Thermal Expansion 9 x 10-6/K

Mechanical Properties of Nichrome Mesh Ni80Cr20:
Bulk Modulus 110 GPa
Tensile Strength 105,000 PSI
Yield strength 50,000 PSI
Endurance Limit 130 MPa
Modulus of Rupture 170 Mpa
Young's Modulus 150 GPa
Specific Heat J/Kg.K
Latent Heat of Fusion 275 Kj/kg
Modulus of Elasticity 31 x 106 PSI

Characteristics of Nickel Chromium Wire Mesh/Screen
1. High mechanical strength, shockproof ability in thermal state and anti-oxidization
2. Utilized for resistance heater elements operating at high temperatures.
3. Great deformation ability and , thermal strength
3. Large electric resistivity and superior resistance to oxidation at high temperatures
4. Nickel Chromium Wire Mesh/Screen forms a protective layer of chromium oxide.

Applications of Nickel Chromium Wire Mesh
1. Heating elements, electric furnace heating and heat-treating processes in the chemical, mechanical, metallurgical and defense industries.
2. Electric ovens, toasters, vacuum coating, and inner components of vacuum valves.
3. Electronic industry.
