Stainless Steel 310S Tube

Heanjia Super Metals Co., Ltd is a qualified manufacturer of austenitic Stainless Steel 310S Tube that is highly resistant to corrosion and oxidation, endows large ductility and excellent welding features. It is also negligibly inclined to embrittelment. It is utilized in the high temperatures of 1150°C for long period and moderately up to 1035°C temperature.

Specification:
Thickness 1-20mm
Out Diameter 16-219mm

Chemical composition of Stainless Steel 310S Tube
Carbon 0.25 max 0.08 max
Silicon 1.50 max 1.50 max
Manganese 2.00 max 2.00 max
Phosphorus 0.045 max 0.045 max
Sulphur 0.030 max 0.030 max
Chromium 24.00 - 26.00 24.00 - 26.00
Nickel 19.00 - 22.00 19.00 - 22.00

Mechanical Properties of 310/310S Stainless Steel Tube
Grade 0.2 % Proof Stress MPa (min) 205
Tensile Strength MPa (min) 520
Elongation % (min) 40
Hardness (HV) (max) 225

Physical Properties of 310/310S Stainless Steel Tube
Density 8,000 Kg/m3
Electrical Conductivity 25°C 1.25 %IACS
Electrical Resistivity 25°C 0.78 Micro ohm.m
Modulus of Elasticity 20°C 200 GPa
Shear Modulus 20°C 77 GPa
Specific Heat 500 J/kg.°C

Characteristics of Stainless Steel 310S Tube
1. High Tensile strength
2. Extremely hard
3. Excellent resistance to oxidation and corrosion
4. Readily formed for welding
Applications of Stainless Steel 310S Tube
1. Furnaces
2. Carburising boxes
3. Heat Exchanging equipments
4. Oil Burners
