Flattened Expanded Nickel-Chromium Alloy Mesh

Ni80Cr20 is alloy of 80% nickel and 20% chromium by weight. Nichrome Mesh is a name for a nickel-chromium alloy mesh. Nickel Chromium Alloy Mesh is corrosion resistant, and has a high melting point of about 1400ºC(2552ºF). Meanwhile, it is relatively high resistivity and resistance to oxidation at high temperatures.


Mesh Specifications Available:
LWM: 4.5MM-100MM
Thickness: 0.1mm to 8.0MM
Width: 0.5MM-8.0MM

SWM: 2.5MM-50MM
Width: 0.9M-2.4M Length: 15M-30M
Thickness: 0.06m m and above, aperture rate: 5%-95%

Properties of Nichrome Mesh Ni80Cr20:


Nickel Chromium alloys Comparison:
Material Cr20Ni80 Cr30Ni70 Cr15Ni60 Cr20Ni35 Cr20Ni30
Component % Ni Remnant Remnant 55.061.0 34.037.0 30.034.0
Cr 20.023.0 28.031.0 15.018.0 18.021.0 18.021.0
Fe ≤1.0 ≤1.0 Remnant Remnant Remnant
Highest temperature 1200 1250 1150 1100 1100
Melting point 1400 1380 1390 1390 1390
Density g/cm3 8.4 8.1 8.2 7.9 7.9
Resistance ratio μΩ•m,20 1.09±0.05 1.18±0.05 1.11±0.05 1.04±0.05 1.04±0.05
Extend ratio % ≥20 ≥20 ≥20 ≥20 ≥20
Specific heat J/g. 0.44 0.461 0.494 0.5 0.5
coefficient of heat conductivity KJ/m.h 60.3 45.2 45.2 43.8 43.8
Wire expand coefficient a×10-6/201000 18 17 17 19 19
Micro-organization Austenite Austenite Austenite Austenite Austenite
Magnetism Non-magnetism Non-magnetism Non-magnetism Non-magnetism Non-magnetism




Nickel Chromium Expanded Mesh --- Types:

Flattened Expanded Mesh:
Flattened Expanded Mesh is produced by passing standard mesh through heavy rolls that flatten the strands and bridges to provide an overall level surface. This process, which reduces the original thickness by approximately one gauge, delivers a product particularly suited to applications where a slid able surface is required.

Advantages of Expanded Mesh Sheet:

1.Expanded metal permits free flow of light, heat, sound and air
2.Expanded metal is available in a variety of mesh configurations including diamond, square, round, hexagonal plus architectural and decorative patterns
3.Expanded Metal is easily fabricated, finished, installed and formed
