Cu90/Ni10 Wedge Wire Screen supplier in Slovakia

Cu90/Ni10 Wedge Wire Screen is implemented in the commercial underwater operations as it offers very high resistance to biofouling and running sea water. It resists erosion and abrasive fluids. The alloy possesses high mechanical properties and strength. For detail.
The Cu90/Ni10 Wedge Wire Screen is a blend of surface outlines and supporting outlines, fusion welded at every joint. The wedge wire screen is manufactured to isolate, categorize, spread, sustain and filter in multitude of commercial processes, fetching mechanical strength and durability in the diverse operations.
We use TIG, MIG and MMA welding methods to produce Cu90/Ni10 Wedge Wire Screen. The water stream, laser and plasma are used for cutting. Our wedge wire screen offers high load bearing competencies, rupturing and disintegrating strength, above of all, the best functioning of finished wire screen.
Applications of Cu90/Ni10 Wedge Wire Screen
1.Solid-liquid and Solid-gas isolation
2.Ground water extraction
3.Crude oil and natural gas production
4.Water processing
5.Mining and aggregate treatment
6.Refining and petrochemical processes

Properties of Cu90/Ni10 Wedge Wire Screen
1.Resistance to over loading
2.Excellent screening performance with wide open area percentage
3.High mechanical strength and durability
4.Resilience to adhere in the arduous environment

Series Dimensions Slot gap (mm)
A B 0.05 0.075 0.10 0.15 0.20
10 SB 0.75 1.30 Open area% 6.30 9.10 11.80 16.67 21.10
Kg/m2 7.26 7.05 6.85 6.50 6.18
11SB 0.75 1.80 Open area% 6.30 9.10 11.80 16.67 21.10
Kg/m2 10.02 9.63 8.96 7.75 7.43
12SB 1.00 1.70 Open area% 9.10 13.04 16.70 20.00 23.08
Kg/m2 10.15 9.80 9.34 9.10 8.67
